Analog Data

1 Diagnostic Link

Diagnostics >> System Function >> RF >> UPM Diagnostics

Diagnostics >> Hardware Location >> System Cabinet >> CAM >> UPM Diagnostics

Figure 1. Analog Data - UPM Diagnostics

2 Purpose

The UPM Diagnostic reads the power supply information from the UPM board.

3 Components Tested

  • UPB Negative 12 Volt

  • UPB Positive 12 Volt

  • RFNB Positive 12 Volt

  • RFBB Positive 12 Volt

  • UPB Positive 5 Volt

  • RFNP Positive 5 Volt

  • RFBB Positive 5 Volt

  • UPB Positive 3.3 Volt

  • RFNP Positive 3.3 Volt

  • RFBB Positive 3.3 Volt

  • UPB Positive 1.5 Volt

  • UPB Positive 1.65 Volt

  • RFNP VREF

  • RFBB VREF

  • RFNP Board Temperature

  • RFBB Board Temperature

4 Requirements

No special requirements.

5 Test Sequence

  1. Select Analog Data from the UPM Diagnostics screen.

  2. Modify Test Parameters as necessary.

  3. Click the Run button.

The Analog Data test reads the power supply information from the UPM board every 5 seconds for the specified test duration (max 300 secs). No error messages will be logged for failing power supplies since the applications code will be logging these errors automatically.

6 Expected Results

A blue color indicates a normal result.
